Electra™ Model

Description

The Electra™ Model was designed as an alternative to Arm-R-Lite’s Titan™ Model to provide the most light transmission with its narrow profile rails and stiles. Since 1958, Arm-R-Lite has been consistently manufacturing the Electra™ Model and has never compromised on the quality of our doors. Because of this, Arm-R-Lite is able to produce replacement sections for any of our welded models, regardless of purchase date. In addition, the Electra™ Model comes with an unmatched 20-year welded frame warranty except for the top section when trolley operated.

  • Maximum Width of 16’-2”
  • Narrow Rails and Stiles
  • 20-Year Welded Frame Warranty*



Specifications:
Material: 6063-T6 Alloy
Construction Method: Heli-Arc Welding
Top Rail: 2 ¾”, 4 ½”, or 7 ½”
Bottom Rail: 2 ¾”, 4 ½”, or 7 ½”
End Stiles: 3 3⁄₈”, 4 ½” or 7 ½”
Center Stiles: 1 3⁄16”
Meeting Rails: 2 ¾” wide per pair**
Frame Thickness: 1 ¾”

Custom Garage Door Options:
Due to our exclusive welded construction, Arm-R-Lite’s aluminum overhead sectional doors are capable of the highest degree of customization. Many of the options listed below are exclusive to Arm-R-Lite due to our superior construction method.

Glass Glazing Options:

  • DSB / Annealed
  • Tempered / Safety
  • Acrylic
  • Laminated
  • Insulated



Glass Thickness:

  • 1/8” non-insulated
  • 1/4” non-insulated
  • 7/16” insulated
  • 5/8” insulated
  • 1” insulated
  • Acoustical*
  • Frosted
  • Tinted
  • Polycarbonate
  • Custom



Panel Options:

  • Solid
  • Stamped Panel Designs
  • Insulated
  • Operable / Inoperable Louvers
  • Perforated
  • Custom Panels
  • Mesh



Finish Options:

Anodized Finishes:
The standard finish is clear anodized aluminum. Optional anodized finishes include dark bronze and black for an upgrade. Includes a 20-year finish warranty except on installations within 1 mile of saltwater.

Fluropon® Finishes:
Upgrade option featuring hundreds of colors including metallic and non-metallic options. Custom color matches are also available upon request. Includes a 20-year finish warranty except on installations within 1 mile of saltwater.

RAL Powdercoat:
Upgrade option featuring over 150 color choices to be selected from RAL color chart. Includes 1-year finish warranty except on installations within 1 mile of saltwater.

Faux Wood: Upgrade option featuring 6 faux wood finishes. Includes a 10-year finish warranty except on installations within 1 mile of saltwater.

Custom Options:

  • Step-Over Pass Door*
  • Sloping Bottom
  • Awning Windows
  • Mail Slots
  • Energy Efficiency Package
  • Motor or Manual Operation
  • Corrosion Resistant Package
  • High Cycle Springs
  • Exhaust Ports
  • Matching Transoms, Side Lites, and Entrance Door



*Please consult with Arm-R-Lite regarding limitations.
